JIS F 7368 Bronse 10K Rising Stem Type Gate Valves Kategori: JIS Marine Gate Valve Materiale: Bronse Standarder: JIS F7368 Sertifikat: CCS, BV, GL, NK, RINA, ABS, DNV, LRFob Pris: Få siste pris nå Opprinnelsessted: Kina
Opprinnelsessted: Kina
China Marine Bronse Gate Valve JIS F7368 10K:
Designstandard: JIS F7368-1996
Teststandard: JIS 7400-1996
Hydraulisk testtrykk: kropp - 2,1 MPa, sete - 1,54 MPa
Flensstørrelse i henhold til JIS B2220 - 10K
Hovedmateriale:
Kropp: Bronse (BC6)
Panser: Bronse (BC6)
Plate: Bronse (BC6)
Stamme: Messing (C3771BD)
Pakning: ikke-asbest
IMPA-KODE | Størrelse | L | D | C | Nr av Bolt Hole | h | t | H | D2 |
750961 | 15 | 100 | 95 | 70 | 4 | 15 | 12 | 175 | 80 |
750962 | 20 | 110 | 100 | 75 | 4 | 15 | 14 | 200 | 100 |
750963 | 25 | 120 | 125 | 90 | 4 | 19 | 14 | 220 | 125 |
750964 | 32 | 140 | 135 | 100 | 4 | 19 | 16 | 250 | 125 |
750965 | 40 | 150 | 140 | 105 | 4 | 19 | 18 | 290 | 140 |
